Astell&Kern ACRO CA1000

To realize any hidden potential and run the most sophisticated and power-hungry headphones a dedicated amplifier is essential. The ACROCA1000 supports a four-step Gain Level setting that can run high-impedance headphones with a 15 V output level - without deterioration of sound quality. Equipped with balanced 2.5mm and 4.4mm and unbalanced 3.5mm and 6.35mm outputs, the ACRO CA1000 can accommodate a wide variety of headphones. Using ultra-small relay parts, circuits for each output are physically separated from each other to minimize any internal noise interference that can adversely affect the quality of the signal and sound.

A digital-to-analog converter (DAC) contributes majorly to how close to the original recording the listener will experience. With a pedigree of designing and engineering award-winning premium DAPs Astell&Kern knowledge of DAC technology is unprecedented. The ACRO CA1000 arrives with a high-quality, high-performance Quad ES9068AS DAC that delivers a clear, detailed, and balanced sound without distortion. The Quad-DAC also supports high-resolution audio playback up native DSD512 and 32 bit/384 kHz, enabling the music fan to get even closer to the original studio sound, while revealing musical details never heard before.

First introduced in the A&futura SE180 DAP, the ACRO CA1000 features Astell&Kern's patented Teraton Alpha technology. As the result of extensive research and development, this sound solution is designed to deliver audio playback close to the original sound through the audio output interface by use of effective power noise removal, efficient power management, and amplification with minimal distortion.

In a headphone environment where the left and right channels are clearly separated, ear fatigue can increase when listening over long periods. Activate the Crossfeed function and a more comfortable listening experience is revealed. This mode has the effect of blending the left and right channels, relieving ear fatigue by creating a more natural sound akin to listening to speakers. In this setting Shelf Cutoff, Shelf Gain, and Mixer Levels are adjustable according to listening tastes.

More than just a powerful headphone amp, the ACRO CA1000 also features DAP capabilities, transforming it into the go-to system for head-fi aficionados. A tilting 4.1-inch touchscreen (up to 60-degrees) enables easy control of the player and amp settings with an intuitive Android OS and feature set taken from its award-winning portable DAPs.

Although not entirely mobile as an Astell&Kern DAP, this amp player hybrid system is compact and portable. Equipped with an 8,400mAh large capacity battery, the ACRO CA1000 can provide up to 10.5 hours of playback without a separate power supply. This headphone amp also supports USB-PD 2.0 (9 V/3 A) fast charging, so anyone with a charger that supports USB Power Delivery (USB-PD) can experience improved charging times - a one-hour charge provides 50% battery, while it takes 2.5 hours for a full charge. A green light on the CA1000 will indicate when USB-PD fast charging is active.

An array of inputs and outputs allows the connection of digital and analog sources to expand the system's capabilities. These include Optical, Coaxial, Type-C USB digital inputs/outputs, and RCA analog input/output. The ACRO CA1000 harbors 256GB on-board memory that can be expanded up to 1TB via a microSD card slot, meaning users can stockpile thousands of hi-res albums. Elsewhere, Replay Gain functionality automatically and uniformly adjusts volume playback from sound sources up to 24-bit/192 kHz so playlists can be enjoyed throughout without reaching for the volume.

A BT Sink function connects the ACRO CA1000 to an external device, such as a smartphone, via Bluetooth, enabling music to be played back in high-quality on the headphone amp. Elsewhere the ACRO CA1000 boasts Bluetooth 5.0, providing greater range and a more stable wireless connection to headphones and, along with support for 24-bit aptX HD and LDAC codecs, offers the best possible wireless sound quality. Alongside dual-band Wi-Fi support, the ACRO CA1000 features AK File Drop for easier wireless file transfers. Users can wirelessly transfer files through a PC, smartphone, or FTP program located on the same network to make music management even more convenient.

The ACRO CA1000's beautifully engineered aluminum body shape and the prominent and tactile volume wheel design are inspired by rugged space-age exploration vehicles that power across planetary terrain. The system still retains Astell&Kern's signature angular shadow and light motif to seamlessly fit into the company's bold and aspirational design language. The Astell&Kern ACRO CA1000 is priced at £1999/$2100/€2299 and will be available from February 2022. Info and photos by Astell&Kern via Armour Home.
